Bosch Rexroth IndraDrive CsDrive System with HCS01 User Manual

Country of use: USA/Canada
Fuse I
N
Current carry‐
ing capacity I
Z
[A]
Cross section A
Installation type E
1 × 2 × 3 × 4 ×
600 475 750 kcmil
600 490 800 kcmil
600 520 900 kcmil
800 545 1000 kcmil
800 590 1250 kcmil
800 625 1500 kcmil
800 650 1750 kcmil
800 665 2000 kcmil
200 300 2 × 1/0 AWG
225 350 2 × 2/0 AWG
250 400 2 × 3/0 AWG
300 460 2 × 4/0 AWG
300 510 2 × 250 kcmil
350 570 2 × 300 kcmil
350 620 2 × 350 kcmil
400 670 2 × 400 kcmil
450 760 2 × 500 kcmil
600 840 2 × 600 kcmil
600 920 2 × 700 kcmil
600 950 2 × 750 kcmil
600 980 2 × 800 kcmil
800 1040 2 × 900 kcmil
800 1090 2 × 1000 kcmil
200 450 3 × 1/0 AWG
225 525 3 × 2/0 AWG
250 600 3 × 3/0 AWG
300 690 3 × 4/0 AWG
300 765 3 × 250 kcmil
350 855 3 × 300 kcmil
350 930 3 × 350 kcmil
400 1005 3 × 400 kcmil
450 1140 3 × 500 kcmil
200 600 4 × 1/0 AWG
Bosch Rexroth AG DOK-INDRV*-HCS01******-PR05-EN-P322/341
Rexroth IndraDrive CsDrive Systems with HCS01
Appendix
