Time behavior
Description Unit min. max.
Test pulse width (t
PL
) μs 100 200
Periodic time (T
P
) ms 500 1000
Phase shift between two test pulses on both channels
(φ)
ms 50 -
Tab. 7-35: Time behavior
DOK-INDRV*-HCS01******-PR05-EN-P Bosch Rexroth AG 225/341
Rexroth IndraDrive CsDrive Systems with HCS01
Technical data of the components
