5. Put heat shrink tubing on shield braid and shrink it. Optional: Mount wire
end ferrules.
Fig. 8-9: Heat shrink tubing, wire end ferrules
6. Connect cable shield to plate from accessories. Optional: Fasten cable
with cable tie.
Fig. 8-10: Shield connection
DOK-INDRV*-HCS01******-PR05-EN-P Bosch Rexroth AG 257/341
Rexroth IndraDrive CsDrive Systems with HCS01
Cables, accessories, additional components
