Property damage due to temperatures higher
than 105 ℃!
Observe the indicated minimum distances!
Above the devices there may only be such materials which
● are not combustible
● are insensitive to the occurring high temperatures
A Air intake
B Air outlet
C Mounting surface in control cabinet
d
top
Distance top
d
bot
Distance bottom
d
hor
Distance horizontal
Fig. 4-10: Air intake and air outlet at device
Bosch Rexroth AG DOK-INDRV*-HCS01******-PR05-EN-P66/341
Rexroth IndraDrive CsDrive Systems with HCS01
Combining the individual components
