USA/Canada; installation type E
Country of use: USA/Canada
Fuse I
N
Current carry‐
ing capacity I
Z
[A]
Cross section A
Installation type E
1 × 2 × 3 × 4 ×
2 1.6 14 AWG
4 3.3 14 AWG
6 5 14 AWG
10 8.3 14 AWG
16 13 14 AWG
20 15 14 AWG
25 20 12 AWG
40 30 10 AWG
70 50 8 AWG
80 65 6 AWG
100 85 4 AWG
110 100 3 AWG
125 115 2 AWG
150 130 1 AWG
175 150 1/0 AWG
200 175 2/0 AWG
225 200 3/0 AWG
250 230 4/0 AWG
300 255 250 kcmil
300 285 300 kcmil
350 310 350 kcmil
350 335 400 kcmil
400 380 500 kcmil
450 420 600 kcmil
600 460 700 kcmil
600 475 750 kcmil
600 490 800 kcmil
600 520 900 kcmil
800 545 1000 kcmil
800 590 1250 kcmil
800 625 1500 kcmil
800 650 1750 kcmil
DOK-INDRV*-HCS01******-PR05-EN-P Bosch Rexroth AG 91/341
Rexroth IndraDrive CsDrive Systems with HCS01
Combining the individual components
