Brother MFC-J6510DW

3-89
Confidential
Assembling Note: After mounting the speaker and its spring into the pocket provided on the
upper cover, route the speaker harness through the cable guides on the upper cover as shown
above. (See also the figure on the previous page.)
(3_054_2)
Speaker
Upper cover
Cable guides
Cable guides
Speaker harness
