Brother MFC-J6510DW Service Manual

2-6
Confidential
 Printing and paper feeding
Names Functions
T1 paper pull-in rollers
These rollers pull in recording paper from paper tray #1.
T2 paper pull-in rollers
These rollers pull in recording paper from paper tray #2.
Paper feed sensor actuator
This detects whether recording paper is fed from the paper tray by
detecting the leading edge of the paper for driving the intermediate
roller.
This also detects paper jams in the rear section of the machine.
Intermediate roller
This stops the leading edge of recording paper for alignment
(registration).
After registration, this roller rotates to feed the recording paper to
the paper feed roller.
Registration sensor actuator
This detects the leading and trailing edges of recording paper for
indicating the printing start position and for judging the paper size,
respectively.
In manual paper feeding, this detects whether recording paper is set
on the manual feed slot.
This also detects paper jams in the rear section of the machine.
Paper feed roller
This feeds recording paper to the printing position.
Recording paper ejection roller This feeds printed recording paper to the switchback roller.
Switchback paper detection
actuator
This detects whether printed recording paper is ejected.
In duplex printing, it detects the trailing edge of the paper after
printing on the first side to determine the reversing timing of the
switchback roller, as well as judging the paper size.
In duplex printing, it also detects whether recording paper has
passed through the DX chute or jammed in the DX chute.
This also detect paper jams in the paper ejection section.
Switchback roller
This ejects recording paper to the paper ejection tray.
In duplex printing, after feeding of recording paper printed on its
first side by the specified amount, this roller reverses to feed the
paper to the duplex print paper path.
DX roller
In duplex printing, this roller feeds paper passing through the duplex
print paper path, to the intermediate roller.

Brother MFC-J6510DW Specifications

General

Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Economical printing	Yes
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	4
Scan to	E-mail, File, FTP, Image, OCR
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	A3 (297 x 420) mm
Output color depth	24 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	2400 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	23 cpm
Copy speed (color, normal quality, A4)	20 cpm
Faxing	Color faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JPEG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	100
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	50 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	35 sheets
Processor family	RISC
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, SDHC
Sound pressure level (printing)	50 dB
Display	LCD
Product color	Black
Display diagonal	3.3 \
Market positioning	Business
Custom media width	148 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 431.8 mm
Paper tray media types	Glossy paper, Photo paper, Plain paper, Transparencies
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
Photo paper sizes (imperial)	5x7, 5x8 \
Borderless printing media sizes	5x7, A3, A4, A6, Index card, Letter
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-PSK
Mobile printing technologies	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Scan speed	3.49 sec/page
Dimensions (WxDxH)	540 x 489 x 257 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, fax, print, scan
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.5 W
Power consumption (PowerSave)	4 W
Power consumption (average operating)	26 W
Sustainability certificates	ENERGY STAR
Package weight	22.400 g
Bundled software	Brother MFL-Pro Suite\\r Brother ControlCentre4 (Win)\\r Nuance® Paperport® 12 SE + OCR (Win)\\r Reallusion® FaceFilter Studio (Win8)\\r Brother ControlCentre2 (Mac)\\r NewSoft® Presto!® PageManager9 (Mac)
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	489 mm
Width	540 mm
Height	257 mm
