Brother MFC-J6510DW

2-61
Confidential
2.4.2 Paper Feeding Problems
Problems related to paper feeding are end user recoverable if following the User Check items. If
the same problem occurs again, follow each procedure in the order of the number described in
the Step column in the tables below.
2.4.2.1 No paper feeding
 Paper is not fed from paper tray #1 (Error code 18, 82, etc.)
User Check
- Check that the paper is loaded in paper tray #1 correctly.
- Check that paper tray #1 is set.
- Check that the jam clear cover is closed.
- Check that the recording paper weight is 75 to 105 g/m
2
.
- Clean the related rollers.
 Paper is not fed from paper tray #2 (Error code 18, 82, etc.)
User Check
- Check that the paper is loaded in paper tray #2 correctly.
- Check that paper tray #2 is set.
- Check that the jam clear cover is closed.
- Check that the recording paper weight is 75 to 105 g/m
2
.
- Clean the related rollers.
Step Cause Solution
1 ASF motor harness connection
failure
Check the connection and reconnect the harness.
2 Paper feed sensor defective Replace the PF encoder/PF sensor harness unit.
3 T1 paper pull-in rollers worn out Replace the rollers.
4 ASF motor defective Replace the ASF drive ASSY.
5 Engine unit defective Replace the engine unit.
6 Main PCB defective Replace the main PCB ASSY.
Step Cause Solution
1 ASF motor harness connection
failure
Check the connection and reconnect the harness.
2 T2 paper pull-in rollers worn out Replace the rollers.
3 ASF motor defective Replace the ASF drive ASSY.
4 Engine unit defective Replace the engine unit.
5 Main PCB defective Replace the main PCB ASSY.
