Brother MFC-J6510DW

2-47
Confidential
 Error Code 83
Recording paper jam in paper feeding. (The registration sensor does not come ON.)
User Check
- Remove the jammed paper.
- Check whether the recording paper being used is within the specification.
Paper Jam
LCD
Step Cause Solution
1 Foreign materials inside the
engine unit
Remove foreign materials.
2 Registration sensor actuator out of
place
Set the actuator into place.
3 Registration sensor harness
connection failure
Check the connection and reconnect the harness.
4 Registration sensor defective Replace the registration sensor PCB ASSY.
5 Paper feed motor defective Replace the paper feed motor.
6 Paper feed roller worn out Replace the engine unit.
7 Main PCB defective Replace the main PCB ASSY.
8 Intermediate roller worn out Replace the engine unit.
