Brother MFC-J6510DW

2-62
Confidential
 Paper cannot be fed from the manual feed slot
User Check
- Check that recording paper is loaded in the manual feed slot correctly.
2.4.2.2 Double feeding
User Check
- Check that recording paper is loaded correctly in each of paper trays.
- Check that the recording paper weight is 75 to 105 g/m
2
.
- Fan the stack of recording paper well and reload it into the paper tray.
- Clean the related rollers.
Step Cause Solution
1 Registration sensor actuator out of
place
Set the actuator into place.
2 Connection failure of the
registration sensor harness
Check the connection and reconnect the harness.
3 Paper feed motor harness
connection failure
Check the connection and reconnect the harness.
4 Registration sensor defective Replace the registration sensor PCB ASSY.
5
Paper feed motor defective
Replace the paper feed motor.
6
Engine unit defective Replace the engine unit.
7
Main PCB defective
Replace the main PCB ASSY.
Step Cause Solution
1
Bank ASSY worn out Replace the bank ASSY.
2 Base pad worn out Replace the base pad.
