Brother MFC-J6510DW Service Manual

4-43
Confidential
4.4 IF YOU REPLACE THE INK ABSORBER BOX OR FLUSHING BOX
When either the ink absorber box or flushing box is replaced, you should replace both of them.
[ 1 ] Reset each of the purge and flushing counts
(1) Switch the machine to the maintenance mode. (Refer to Chapter 5.)
(2) Press the 8 and 0 keys in this order.
(3) Press the Black Start (Mono Start) key several times until the purge (or flushing) count
appears on the LCD.
(4) Press the 2, 7, 8, and 3 keys in this order to reset the purge (or flushing) count.
(5) Press the Stop/Exit key to return to the initial stage of the maintenance mode.
(6) Press the 9 key twice to exit from the maintenance mode.
Tip: This machine counts all purge operations and flushing operations performed since
produced in order to prevent the ink absorber box and flushing box from overflowing with
drained and flushed ink, respectively. An initial purge, for example, advances the count by 569.
When the purge or flushing count approaches 15,350
or 698,469,595, respectively, the
"MACHINE ERROR 46" appears and further purge or flushing operations are prohibited.
Replace the ink absorber box and flushing box, and then reset their counts.
4.5 IF YOU REPLACE THE CONTROL PANEL ASSY, CONTROL PANEL
PCB OR LCD UNIT
[ 1 ] Adjust the touch panel (Function code 78) (For models with touch panel)
Refer to Chapter 5, Section 5.1.4.29.
Note: This operation is not required when only the control panel PCB is replaced.
[ 2 ] Check LCD operation (Function code 12)
Refer to Chapter 5, Section 5.1.4.7.
Note: This operation is not required when only the control panel PCB is replaced.
[ 3 ] Check the operation of the control panel PCB (Function code 13)
Refer to Chapter 5, Section 5.1.4.8.
Note: This operation is not required when only the LCD unit is replaced.

Brother MFC-J6510DW Specifications

General

Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Economical printing	Yes
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	4
Scan to	E-mail, File, FTP, Image, OCR
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	A3 (297 x 420) mm
Output color depth	24 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	2400 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	23 cpm
Copy speed (color, normal quality, A4)	20 cpm
Faxing	Color faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JPEG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	100
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	50 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	35 sheets
Processor family	RISC
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, SDHC
Sound pressure level (printing)	50 dB
Display	LCD
Product color	Black
Display diagonal	3.3 \
Market positioning	Business
Custom media width	148 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 431.8 mm
Paper tray media types	Glossy paper, Photo paper, Plain paper, Transparencies
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
Photo paper sizes (imperial)	5x7, 5x8 \
Borderless printing media sizes	5x7, A3, A4, A6, Index card, Letter
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-PSK
Mobile printing technologies	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Scan speed	3.49 sec/page
Dimensions (WxDxH)	540 x 489 x 257 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, fax, print, scan
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.5 W
Power consumption (PowerSave)	4 W
Power consumption (average operating)	26 W
Sustainability certificates	ENERGY STAR
Package weight	22.400 g
Bundled software	Brother MFL-Pro Suite\\r Brother ControlCentre4 (Win)\\r Nuance® Paperport® 12 SE + OCR (Win)\\r Reallusion® FaceFilter Studio (Win8)\\r Brother ControlCentre2 (Mac)\\r NewSoft® Presto!® PageManager9 (Mac)
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	489 mm
Width	540 mm
Height	257 mm
