2.2.3 Parts Names and Functions
 Document scanning and feeding
Names Functions
Document detection actuator
This detects whether documents are set on the document tray.
Document width detection actuator
This detects whether documents loaded are A4 (letter) or B4/
A3 (ledger) in width.
Document pull-in roller This pulls documents loaded in the document tray into the
ADF.
Document separation roller and
separation rubber
These feed document pages (drawn in by the document pull-
in roller) one at a time to the document feed roller 1.
Document scanning position detection
actuator (for second side scanning)
This detects the leading edge of document pages, indicating
the scanning start position for second side scanning (only in
duplex scanning).
This also detects paper jams in the ADF.
Document feed roller 1 This feeds a document to the CIS unit (for second side
scanning).
Document feed roller 2 This feeds a document to the CIS unit (for first side
scanning).
Document scanning position detection
actuator (for first side scanning)
This detects the leading edge of document pages, indicating
the scanning start position for first side scanning (only in
duplex scanning).
This also detects paper jams in the ADF.
Document ejection roller This ejects document pages that have been scanned, onto the
document cover.
