8 Carriage motor harness and ink cartridge cover sensor ASSY

9 Air vent tube and drain tube

Cable guides

Ferrite core

Carriage motor

harness

Ink cartridge cover

sensor harness

Ink cartridge cover sensor ASSY

Cable guides

Lower cover

Drain tube

Cable guide

Air vent tube
