(5) Release the four Hooks and remove the Ink absorber box cover from the Upper

cover.

Fig. 3-4

(6) Release the six Hooks and remove the Harness cover from the Upper cover.

Fig. 3-5

Hooks

Hook

Ink absorber box cover

Upper cover

Hooks

Upper

Hook

cover

Harness cover

Hooks

Upper

Hook

cover

Harness cover
