(16)Release the Lock spring securing the Carriage PCB.

(17)Release the Hook and remove the Carriage PCB from the Head/carriage unit.

Fig. 3-11

(18)Place the removed Carriage PCB on the position shown in the figure.

Fig. 3-12

Hook

Carriage PCB

Head/carriage unit

Lock spring

Carriage PCB

Head/carriage unit
