(4) Remove the Scanner cover.

Fig. 3-28

Note: The Hook of the Scanner harness holder is easily broken, be sure to place the

Scanner cover in the orientation shown in the figure.

Fig. 3-29

Scanner cover

Machine body

Scanner harness holder

Scanner cover

Hook
