Assembling Note: Assemble a new First side CIS flat cable by bending the First side
CIS flat cable and affixing the Double-sided adhesive tape as
shown in the figure below.
Fig. 3-74
Double-sided
adhesive tape
Supporting tape
55±1
mm
(1.5mm)
(2 mm)
40±1
mm
25±1
mm
10±1
mm
356.6±2
mm
Term inal
Terminal
Supporting tape
45°±3.5°
(66 mm)
374 mm
45°±3.5°
248.4±2
mm
Double-sided adhesive tape
(1.5 mm)
(38
mm)
(1.5 mm)
(10 mm)
Double-sided
adhesive tape
24±1
mm
15±1
mm
To main body
To CIS unit
To main body
To CIS unit
Valley fold
Mountain fold
mm
1045±10
