Figure 8.9: Radiator
1 Radiator 2 Water distributor
3
Expansion tank
2
3
1
5
AE_5iS_0884
4
6
Figure 8.10: Cooling system schematic
1
Expansion tank
2
Pressure cap
3 Radiator 4
Water pump
5 Overflow bottle 6 Vent
