BRP ROTAX 916 i A Series Installation Manual

BRP-Rotax
INSTALLATION MANUAL
BATTERY BACKUP CONTROL
Parameter Value
Contact type Toggle (must not be active during normal
operation)
Nominal voltage
28 V DC
Nominal current 20 A
916 i TYPE C24
START POWER CONTROL
Parameter Value
Contact type Momentary (must not be active after en-
gine start)
Nominal voltage
24 V DC
Nominal current 20 A
BATTERY BACKUP CONTROL
Parameter Value
Contact type Toggle (must not be active during normal
operation)
Nominal voltage
24 V DC
Nominal current 20 A
916 i TYPE C24
The 28 V output of the AC-DC Converter is able to supply a maximum current of 27.9 A. If
this current flow is exceeded, the 28 V output is switched off because an overload has
been detected. The so-called hiccup mode now performs a cyclic activation of the output
and queries the elimination of the overload. This is done in intervals of about three
seconds.
If an accumulator is connected to the 28 V output and its charge state is very low, it can
happen that the charge current exceeds the 27.9 A mentioned above. A switch-off of the
28 V output is the consequence and an overload is permanently detected by the hiccup
mode. Charging the accumulator is therefore not possible.
Effectivity: 916 i A / C24
Edition 0/Rev. 1
24–00–00
Page 23
December 01 2023
