Drive Drive via propeller gearbox.
Position of the propeller connection on the governor flange:
x-axis [mm/in] y-axis [mm/in] z-axis [mm/in]
-206.3 (-8.12)
0
51.5 (2.03)
Connection
NOTICE
Obey the manufacturers instructions!
Technical Data Gear ratio from crankshaft to hydraulic governor is 1.842, i.e. the propeller governor runs
at 0.54 times engine speed.
Mounting pad AND20010
Thread size M8
Thread length
max. 14 mm (0.55 in)
Toothing
Internal spline 20/40 SMS 1834 NA 14x1,27x30x12
Power input max. 600 W
Operating pressure max. 30 bar (435 psi)
Effectivity: 916 i A / C24
Edition 0/Rev. 1
