Section 8. Operation
275
where
Gain
Error
=
±
(2500
*
0.0006)
=
±1.5
mV
and
Offset
Error
=
1.5
•
667
µV
+
1
µV
=
1.00
mV
Therefore,
Error
=
Gain
Error
+
Offset
Error
=
±1.5
mV
+
1.00
µV
=
±2.50
mV
In
contrast,
the
error
for
a
500
‐
mV
input
under
the
same
constraints
is
±1.30
mV.
The
figure
Volt
age
Measurement
Accuracy
(p.
275
)
illustrates
the
total
error
with
respect
to
voltage
measurements
for
the
±2500
‐
mV
range.
Figure 87: Voltage measurement
accu
racy (0° to 40°C)
