Section 4. Quickstart Tutorial
54
4.2.5.4 Procedure: (PC200W Step 6)
6. Click on the Collect Data tab. From this window, data are chosen to be
collected as well as the location where the collected data will be stored.
Figure 23: PC200W Collect Data tab
4.2.5.5 Procedure: (PC200W Steps 7 to 9)
7. Click the OneMin box so a check mark appears in the box. Under What to
Collect, select New data from datalogger. This selects the to be collected.
8. Click on Collect. A dialog box will appear prompting for a filename. Click
Save to accept the default filename of CR800_OneMin.dat. A progress bar
will appear as data are collected, followed by a Collection Complete
message. Click OK to continue.
9. To view the data, click on
at the top of the window to open the View
utility.
