57
Section 5.
System Overview
A Campbell Scientific data-acquisition
system is made up of the following basic
component
s:
•
Sensors
•
Datalogger
o
Clock
o
Measurement and co
ntrol circuitry
o
Telecommuni
cations circui
try
o
User-entered CRBasic program
•
Telecommuni
cations device
•
Datalogge
r support
software
(p.
76)
(computer or mobi
le)
The figure
Features of a Data-Acquisition System
(p.
58)
illustrates a common
CR800-based d
ata-acquisition system.
