Section 8. Operation
298
instruction.
PulseCou
nt()
instruction fu
nctions incl
ude retur
ning count
s or
frequency
on frequency
or swit
ch-closure sig
nals.
TimerIO()
instruction has
additional capabilities. Its primary function is to measure the time between state
transitions.
Note
Consul
t
CRBasic Editor Help
for m
ore information on
PulseCount()
and
TimerIO()
instructions.
Figure 92: Pulse-sensor output signal
types
Figure 93: Switch-closure pulse sensor
297
