Canon imagePROGRAF iPF755 User Guide

Setting Item Description, Instructions
GL2
Set-
tings
Line &
Pen
Man-
ager
Pen
Setup
Select Palette Choose Software to print according to software set-
tings. Choose Palette A or Palette B to print using the
value specified in Define Palette.
Define Palette Specify the Width, Color, and Line Attributes in the
palette Pen no.. Choose Factory to confirm the values
when Factory is selected in Select Palette.
In Line Attributes, choose No Setting or Circle Set-
ting as the processing for the ends and junctions of
lines.
• If you choose No Setting
• If you choose Circle Setting
Reset Palette Restore Define Palette to the default palette settings.
Smoothing Choose whether to print arcs as smooth curved lines or
as multiple connected line segments.
• If you choose Software
Operation is determined by the application. If noth-
ing is specified by the application, the result is as
shown in the figure.
Note: By default, this is a 72-sided figure
• If you choose Smooth
ThickenFineLines Select On to print fine lines more distinctly.
Control Panel > Printer Menu >
iPF755 Menu Settings
9
745
Downloaded from ManualsPrinter.com Manuals

Canon imagePROGRAF iPF755 Specifications

General

Printer Type	Large Format Printer
Maximum Print Resolution	2400 x 1200 dpi
Number of Ink Colors	5
Number of Nozzles	15, 360
Memory (Standard)	256 MB
Hard Drive	80 GB
Ink Droplet Size	4 picoliters
Operating Systems	Windows, Mac OS
Print Technology	Inkjet
Ink Type	Pigment/Dye
Maximum Print Width	36 inches
Connectivity	USB, Ethernet
Media Handling	Roll Feed
Media Width	8 inches to 36 inches
Media Thickness	0.07 - 0.8mm
Ink Colors	Cyan, Magenta, Yellow, Black
Media Sizes	Roll paper: 10"-36" (254mm-914mm), Cut sheet: 8"-36" (203.2mm-914mm)
Media Types	Plain Paper, Coated Paper, Photo Paper
Power Consumption	140W or less
Print Speed (Color)	D-sized print (33.1 x 23.4 inches) in approximately 28 seconds
Print Speed (Black & White)	D-sized print (33.1 x 23.4 inches) in approximately 28 seconds
