CS 7600_User Guide (8J4071)_Ed04 33
4 In the image Acquisition interface, click one of the following:
• Click Apply to apply your settings.
• Click Cancel to exit to the main screen without saving changes.
5 Click OK to save the changes and exit to the main screen.
About Peer to Peer Connection
A Peer to Peer connection (P2P) creates a dedicated link between one, or more, scanners to a dedicated
workstation. When a plate is scanned with a Peer to Peer connection, there is no need to select a
Workstation/Room or press the middle scanner button. The scanner automatically scans the plate as soon as
it is fed into the scanner and sends the image to the Paired workstation.
There are four possible statuses for the Peer to Peer:
• Available for Peer to Peer connection- The scanner is available for a direct Peer to Peer
connection. This status may be identified when the Pair button is available.
• Paired - The scanner is connected Peer to Peer to this Workstation. This status may be identified
when the Paired message is shown and the Unpair button is
available.
• Paired to Doctor x - The scanner is already connected Peer to Peer to another Workstation
• Unavailable for Peer to Peer- This status is when a scanner in the Scanners list is not connected to
your workstation or any other workstation and is not available for connecting to your workstation,
this may be identified by the absence of the Pair button, Paired,
and Paired to messages.
Tip: If your workstation is the only one using a particular scanner you can save time,
not having to select a scanner each time you make a scan, by making a Peer to Peer link
from the scanner to the computer.
Note: The tagged Imaging plate is sent to the proper room, defined by Scan &
Go, even when in Peer to Peer mode.
