CS 7600_User Guide (8J4071)_Ed04 3
2 CS 7600 System Overview
Introduction
CS 7600 is a scanner system for intraoral X-ray exposed imaging plates.
The CS 7600 is intended for digital dental radiography using an imaging plate (storage phosphor plate) for
radiographic diagnostic intraoral images. The CS 7600 system is used to scan and review intraoral dental
X-ray images. When scanning the X-ray exposed imaging plate a digital image is previewed on the
scanner’s LCD and saved to the scanner’s internal memory. After scanning, the scanner erases the imaging
plate and ejects it. The imaging plate is ready for re-use.
The exam acquisition’s scanned image is sent over the network to the workstation’s image Acquisition
interface. Using the image Acquisition interface the image is processed and reviewed.
The image Acquisition interface sends the images to the Dental Imaging Software, which archives the
acquired images.
The scanner connects directly to the network, or is connected peer-to-peer to the workstation.
The scanner can be optionally placed on a desk/counter top or mounted on a wall, using a special shelf
(adapter).
The system is composed of
the following elements:
• CS 7600 scanning device (page 4)
• Smart imaging plates (page 6)
• CS 7600 image Acquisition interface (page 14)
• Scan & Go device (optional, page 9)
Note: The CS 7600 is intended for dental professionals. You are required to
have training to use the CS 7600.
Note: The scanner is supplied with a separate viewing and archiving software
package: Dental Imaging Software, approved by Carestream Health.
Note: The CS 7600 User Guide is also provided as a PDF file on the supplied
CD-ROM.
