6 Chapter 2 CS 7600 System Overview
Smart Imaging Plates Overview
The CS 7600 works with five imaging plate sizes: 0 to 4. The scanned image file size depends on the
imaging plate size and the scanning resolution set by the user.
The smart function of the imaging plates is utilized when using the Scan & Go device.
Table 1 Intraoral Imaging Plate Sizes
Size Illustration Application
0 Periapical exam (Pediatric dentistry)
1 Bitewing exam (Pediatric dentistry)
2 Periapical exam (Adult)
3 Bitewing exam (Adult)
4 Occlusal exam
