CASE CONSTRUCTION 1150M

To Next Page

To Previous Page

7-MAINTENANCE

Remotegreasezerks

Leftside

(1)Leftliftcylinder

(2)C-frame

(3)Equalizerbeam

RAPH12DOZ0042AA1

Rightside

(4)C-frame

(5)Liftcylinder

RAPH12DOZ0061AA2

Greasezerks

Pivotshaft(1)

RAIL14DOZ0400AA3

Equalizerbeam(2)—oneoneitherside

RAIL14DOZ0424AA4

7-36
