3-CONTROLSANDINSTRUMENTS
Cabdoor
WARNING
Fallhazard!
Alwayslockthecabdoorsinthefullopenor
fullclosedpositionbeforeusingthehandrails
onthedoors.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0133A
Doorhandleanddoorlock-Usethekeytolockorunlock
doorfromoutsidethemachine.Usethedoorhandleto
openthedoorfromtheoutside.
Openthedoorcompletelyuntilitlatchesinplaceagainst
thecabtolockthedoorintheopenposition.T oclosethe
door,usethedoorreleaseknob.
NOTE:Thekeyprovidedwiththemachinecanbeused
tolockandunlockthevariouspanelsandtoactivatethe
enginestarterswitchfunctions.
RAIL12DOZ0659AA3
Insidedoorlatch
Tosecurethedoorintheopenpositionfrominsidethe
cab,pushthedoorbackuntilthedoorlocksonthedoor
catchattherearofthecab.
Pushthelatchtoopenthedoorfromtheinside.
RAIL13DOZ1596AA4
