3-CONTROLSANDINSTRUMENTS

Exteriordoorlatch

Pushtheleverdowntounlatchthecabdoorfromtheopen

andlockedposition.

RAIL12DOZ0173AA6

Windowlatch

Rearsidecabwindowscanbeopened.Usethelatchto

openwindows.Pullthelatchtowardsthewindowtoopen.

RAPH12DOZ0107AA7

3-3
