3-CONTROLSANDINSTRUMENTS
Tilt
Movethecontrollevertotheleft(E)totiltthebladetothe
left.
Movethecontrollevertotheright(F)totiltthebladeto
theright.
Thebladewillstopmovingwhenthecontrolleverisinthe
HOLD(C)position.Whenreleased,thecontrolleverwill
returnautomaticallytotheHOLDposition.
RAPH12DOZ0081AA4
Anglingtheblade
Changetheangleofthebladefromsidetosidebymoving
thethumbwheellocatedonthefaceofthejoystick.
RAPH12DOZ0082AA5
Bladeshake
Abladeshakefeatureislocatedonthefaceoftheright
handjoystick.Whenbladeshakeisengaged,thema-
chinewillautomaticallymovethetiltofthebladetoshake
theblade.Pressandholdthebladeshakemomentary
button,andthebladewillshakeatavigorousfrequency
untilreleasedorapproximatelythreeseconds.Leveling
mustbeofftoengagethebladeshakefeature.
RAPH12DOZ0082AA6
3-33
