20-5
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 20 Defining Route Maps
Customizing a Route Map
–
Choose Match Route Source to enable or disable the Match advertising source address of
route.
–
Click the ellipses to display the Browse Access List dialog box.
–
Choose the ACL that you want, and click Selected Access List, then click OK.
• Check the Metric Value check box to enable or disable matching the metric of a route.
–
In the Metric Value field, type the metric values. You can enter multiple values, separated by
commas. This value allows you to match any routes that have a specified metric. The metric
value can range from 0 to 4294967295.
• Check the Route Type check box to enable or disable matching of the route type. Valid route types
are: External1, External2, Internal, Local, NSSA-External1, and NSSA-External2. When enabled,
you can select more than one choice from the list.
Step 6 Click the Set Clause tab to modify the following information, which will be redistributed to the target
protocol:
–
Select the Set Metric Clause check box to enable or disable the metric value for the destination
routing protocol, and type the value in the Value field.
–
Select the Set Metric Type check box to enable or disable the type of metric for the destination
routing protocol, and choose the metric type from the drop-down list.
Customizing a Route Map
This section describes how to customize the route map and includes the following topics:
• Defining a Route to Match a Specific Destination Address, page 20-5
• Configuring the Metric Values for a Route Action, page 20-6
Defining a Route to Match a Specific Destination Address
To define a route to match a specified destination address, perform the following steps:
Step 1 In ASDM, choose Configuration > Device Setup > Routing > Route Maps.
Step 2 Click Add.
The Add or Edit Route Map dialog box appears. From this dialog box you can assign or select the route
map name, the sequence number and its redistribution access (that is, permit or deny). Route map entries
are read in order. You can identify the order using the sequence number, or the adaptive security
appliance uses the order in which you add the entries.
Step 3 Click the Match Clause tab to choose routes to which this clause should be applied, and set the
following parameters:
• Check the Interface check box to enable or disable matching the first hop interface of a route or to
match any routes with the specified next hop interface. If you specify more than one interface, then
the route can match either interface.
–
Enter the interface name in the Interface field, or click the ellipses to display the Browse
Interface dialog box.
