28-33
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 28 Configuring Twice NAT
Configuration Examples for Twice NAT
b. Define the PAT address, and click OK.
Figure 28-70 Defining the PAT Address
c. Choose the new network object by double-clicking it. Click OK to return to the NAT configuration.
Figure 28-71 Choosing the New Network Object
Step 8
For the Translated Destination Address, type the name of the Original Destination Address
(TelnetWebServer) or click the browse button to choose it.
Because you do not want to translate the destination address, you need to configure identity NAT for it
by specifying the same address for the Original and Translated destination addresses.
Figure 28-72 Add NAT Rule Dialog Box: Completed
Step 9
Click OK to add the rule to the NAT table.
Step 10 Add a NAT rule for traffic from the inside network to the web server:
