38-13
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 38 Configuring Inspection for Voice and Video Protocols
MGCP Inspection
–
Calling Party—Match the calling party.
–
Media Type—Match the media type.
• Called Party Criterion Values—Specifies to match on the H.323 called party.
–
Regular Expression—Lists the defined regular expressions to match.
–
Manage—Opens the Manage Regular Expressions dialog box, which lets you configure regular
expressions.
–
Regular Expression Class—Lists the defined regular expression classes to match.
–
Manage—Opens the Manage Regular Expression Class dialog box, which lets you configure
regular expression class maps.
• Calling Party Criterion Values—Specifies to match on the H.323 calling party.
–
Regular Expression—Lists the defined regular expressions to match.
–
Manage—Opens the Manage Regular Expressions dialog box, which lets you configure regular
expressions.
–
Regular Expression Class—Lists the defined regular expression classes to match.
–
Manage—Opens the Manage Regular Expression Class dialog box, which lets you configure
regular expression class maps.
• Media Type Criterion Values—Specifies which media type to match.
–
Audio—Match audio type.
–
Video—Match video type.
–
Data—Match data type.
• Multiple Matches—Specifies multiple matches for the H.323 inspection.
–
H323 Traffic Class—Specifies the H.323 traffic class match.
–
Manage—Opens the Manage H323 Class Maps dialog box to add, edit, or delete H.323 Class
Maps.
• Action—Drop packet, drop connection, or reset.
Modes
The following table shows the modes in which this feature is available:
MGCP Inspection
This section describes MGCP application inspection. This section includes the following topics:
• MGCP Inspection Overview, page 38-14
• Select MGCP Map, page 38-16
• MGCP Inspect Map, page 38-16
Firewall Mode Security Context
Routed Transparent Single
Multiple
Context System
••••—
