Cisco ASR 9000 Series Routing Configuration Guide

DETAILED STEPS
PurposeCommand or Action
configure
Step 1
Enters configure Router Convergence Monitoring
and Diagnostics (rcmd) configuration mode.
router-convergence
Example:
RP/0/RSP0/CPU0:router(config)#router-convergence
Step 2
Configures to collect diagnostics on specified
node.
collect-diagnostics location
Example:
RP/0/RSP0/CPU0:router(config-rcmd)#collect-diagnostics
0/3/CPU0
Step 3
Sets event buffer size 9as number of events) for
storing event traces .
event-buffer-size number
Example:
RP/0/RSP0/CPU0:router(config-rcmd)#event-buffer-size 100
Step 4
Sets maximum number of events to be stored in
the server.
max-events-stored number
Example:
RP/0/RSP0/CPU0:router(config-rcmd)#max-events-stored 10
Step 5
Sets interval (in minutes) to collect logs.
monitoring-interval minutes
Example:
RP/0/RSP0/CPU0:router(config-rcmd)#monitoring-interval 120
Step 6
Configures parameters for a specified node.
node node-name
Step 7
RP/0/RSP0/CPU0:router(config-rcmd)#node
Specifies the protocol for which to configure
RCMD parameters.
protocol
Example:
RP/0/RSP0/CPU0:router(config-rcmd)#protocol ISIS
RP/0/RSP0/CPU0:router(config-rcmd-proto)#
Step 8
•
ISIS-Select ISIS to configure parameters
related to ISIS protocol
•
OSPF-Select OSPF to configure parameters
related OSPF protocol
Sets priority for monitoring of route convergence
for the specified protocol.
priority
Example:
RP/0/RSP0/CPU0:router(config-rcmd-proto)#priority critical
Step 9
•
Critical-Set to monitor route convergence
for critical priority routes
RP/0/RSP0/CPU0:router(config-rcmd-proto-prio)#
•
High-Set to monitor route convergence for
high priority routes
•
Medium-Set to monitor route convergence
for medium priority routes
Cisco ASR 9000 Series Aggregation Services Router Routing Configuration Guide, Release 5.3.x
649
Implementing RCMD
Configuring Route Convergence Monitoring and Diagnostics
