Cisco ASR 9000 Series Routing Configuration Guide

RP/0/RSP0/CPU0:ASR9K-0#show running-config class-map type traffic flowMatch36
Thu Feb 12 01:52:04.838 UTC
class-map type traffic match-any flowMatch36
match flow-tag 36
end-class-map
!
Configuring a VPN Routing and Forwarding Instance in BGP
Layer 3 (virtual private network) VPN can be configured only if there is an available Layer 3 VPN license
for the line card slot on which the feature is being configured. If advanced IP license is enabled, 4096 Layer
3 VPN routing and forwarding instances (VRFs) can be configured on an interface. If the infrastructure VRF
license is enabled, eight Layer 3 VRFs can be configured on the line card.
See the Software Entitlement on Cisco ASR 9000 Series Router module in Cisco ASR 9000 Series Aggregation
Services Router System Management Configuration Guide for more information on advanced IP licencing.
The following error message appears if the appropriate licence is not enabled:
RP/0/RSP0/CPU0:router#LC/0/0/CPU0:Dec 15 17:57:53.653 : rsi_agent[247]:
%LICENSE-ASR9K_LICENSE-2-INFRA_VRF_NEEDED : 5 VRF(s) are configured without license
A9K-iVRF-LIC in violation of the Software Right To Use Agreement.
This feature may be disabled by the system without the appropriate license.
Contact Cisco to purchase the license immediately to avoid potential service interruption.
An AIP license is not required for configuring L2VPN services.Note
The following tasks are used to configure a VPN routing and forwarding (VRF) instance in BGP:
Defining Virtual Routing and Forwarding Tables in Provider Edge Routers
Perform this task to define the VPN routing and forwarding (VRF) tables in the provider edge (PE) routers.
SUMMARY STEPS
1.
configure
2.
vrf vrf-name
3.
address-family { ipv4 | ipv6 } unicast
4.
maximum prefix maximum [ threshold ]
5.
import route-policy policy-name
6.
import route-target [ as-number : nn | ip-address : nn ]
7.
export route-policy policy-name
8.
export route-target [ as-number : nn | ip-address : nn ]
9.
commit
DETAILED STEPS
PurposeCommand or Action
configure
Step 1
Cisco ASR 9000 Series Aggregation Services Router Routing Configuration Guide, Release 5.3.x
137
Implementing BGP
Configuring a VPN Routing and Forwarding Instance in BGP
