CLNS I/O
Protocol State: Up
MTU: 1497
SNPA: 0026.9829.af19
Layer-2 MCast Groups Membership:
All ISs: Yes
IPv4 Unicast Topology: Enabled
Adjacency Formation: Running
Prefix Advertisement: Running
Metric (L1/L2): 110/110
Weight (L1/L2): 0/0
MPLS Max Label Stack: 1
MPLS LDP Sync (L1/L2): Disabled/Disabled
Link-Group (L1/L2): Configured/Configured
Metric-Offset (L1/L2):100/100
IPv4 Address Family: Enabled
Protocol State: Up
Forwarding Address(es): 100.5.6.6
Global Prefix(es): 100.5.6.0/24
LSP transmit timer expires in 0 ms
LSP transmission is idle
Can send up to 9 back-to-back LSPs in the next 0 ms
Configure Link Group Interface
Perform this task to configure link group under Intermediate System-to-Intermediate System (IS-IS) interface
and address-family sub-mode:
One IS-IS interface and address-family can specify only one link-group association. The default is for
both levels regardless of the current circuit-type. The link-group association can be specified for one level
only if configured.
Note
SUMMARY STEPS
1.
configure
2.
router isis instance-id
3.
interface type interface-path-id
4.
address-family ipv4 | ipv6 [ unicast ]
5.
link-group link-group-name [ level {1 | 2 } ]
6.
commit
7.
show isis interface
DETAILED STEPS
PurposeCommand or Action
configure
Step 1
Cisco ASR 9000 Series Aggregation Services Router Routing Configuration Guide, Release 5.3.x
393
Implementing IS-IS
ISIS Link Group

Cisco ASR 9000 Series Specifications

General

Series	ASR 9000
Category	Network Router
Modular Design	Yes
Redundancy	Yes (Hardware and Software)
Operating System	Cisco IOS XR
Interfaces/Ports	10G, 40G, 100G, 400G Ethernet
Expansion Slots	Varies by model
Routing Protocol	BGP, OSPF, IS-IS, EIGRP
Management	CLI, SNMP, NETCONF
Power Supply	Redundant
Port Density	Varies by model
Power Supply Options	AC, DC
Memory	Varies by model
Storage	Varies by model
Dimensions	Varies by model
Weight	Varies by model
