Cisco ASR 9000 Series Routing Configuration Guide

PurposeCommand or Action
Enables the source RLOC based decapsulation
filtering feature.
decapsulation filter rloc source [ locator-set locator_set_name ][
members ]
Example:
RP/0/RSP0/CPU0:router(config-lisp)#decapsulation filter
Step 12
•
The members keyword enables the
establishment of a reliable transport (TCP)
session with configured Map-Server(s), and
the download of the decapsulation filer list
rloc
source member locator-set loc_sh1_vrf1
maintained by the Map-Server(s)and the
download of the decapsulation filer list
maintained by the Map-Server(s)
•
The locator-set keyword is used, the prefixes
named in the locator-set are used, if included
alone, or added to the (downloaded) dynamic
list when used in conjunction with the
member keyword.
Associate a virtual routing and forwarding (VRF)
table through which the routing locator address
locator-table name [ default | vrf vrf_name]
Example:
RP/0/RSP0/CPU0:router(config-lisp)#locator-table vrf 1
Step 13
space is reachable to a router Locator ID Separation
Protocol (LISP) instantiation.
commit
Step 14
In this example, an xTR is configured to establish a reliable transport session with the Map-Server at 204.1.0.1,
download the decapsulation filter list (in this case for IID 1002), and source-check all LISP-encapsulated
packets using this filter list prior to decapsulation.
router lisp
address-family ipv4 unicast
!
locator-set loc_sh1_vrf1
202.1.0.1
203.1.0.1
!
eid-table vrf sh1_vrf2 instance-id 1002
address-family ipv4 unicast
etr map-server 204.1.0.1 key encrypted lisp
etr
itr map-resolver 204.1.0.1
itr
map-cache 12.2.0.0/24 map-request
map-cache 102.2.0.0/24 map-request
map-cache 103.2.0.0/24 map-request
database-mapping 11.2.0.0/24 201.1.0.1 priority 1 weight 100
database-mapping 101.2.0.0/24 201.1.0.1 priority 1 weight 100
!
decapsulation filter rloc source member locator-set
loc_sh1_vrf1
!
locator-table default
Cisco ASR 9000 Series Aggregation Services Router Routing Configuration Guide, Release 5.3.x
666
Implementing Data Plane Security
Enable Source RLOC-based Decapsulation Filtering
