Cisco ASR 9000 Series Routing Configuration Guide

PurposeCommand or Action
Specifies the IPv4 or IPv6 address family, and
enters address family configuration mode.
address-family { ipv4 | ipv6 } unicast
Example:
RP/0/RSP0/CPU0:router(config-lisp-afi)# address-family ipv4
unicast
Step 6
•
This example specifies the unicast IPv4
address family.
Specifies the options related to the etr map-server
(MS) such as locator and authentication key.
etr map-server IP_address { key [ clear | encrypted] LINE |
proxy-reply }
Example:
RP/0/RSP0/CPU0:router(config-lisp-afi)#etr map-server
204.1.0.1 key encrypted lisp
Step 7
Configures an IPv4 or IPv6 locator address of the
LISP Map-Resolver to be used by the ITR
itr map-resolver map-resolver-address
Example:
RP/0/RSP0/CPU0:router(config-lisp-afi)#itr map-resolver
204.1.0.1
Step 8
Map-Requests for IPv4 EID-to-RLOC mapping
resolution.
Configures a static IPv4 EID-to-RLOC or static
IPv6 EID-to-RLOC mapping relationship and its
map-cache destination-EID-prefix / prefix-length { action { drop |
map-request | native-forward} | locator locator-address priority
priority_value | weight weight_value
Step 9
associated traffic policy, or statically configure the
packet handling behavior associated with a
Example:
RP/0/RSP0/CPU0:router(config-lisp-afi)#map-cache 12.2.0.0/24
destination IPv4 EID-prefix or a destination IPv6
EID-prefix.
map-request
RP/0/RSP0/CPU0:router(config-lisp-afi)#map-cache
102.2.0.0/24 map-request
RP/0/RSP0/CPU0:router(config-lisp-afi)#map-cache
103.2.0.0/24 map-request
Configures an EID-to-RLOC mapping relationship
and its associated traffic policy for this LISP site.
Repeat this step until all EID-to-RLOC
mappings within this eid-table vrf and
instance ID for the LISP site are
configured.
Note
database-mapping EID-prefix/prefixlength locator locator-set site
priority priority weight weight
Example:
RP/0/RSP0/CPU0:router(config-lisp-afi)#database-mapping
11.2.0.0/24 201.1.0.1
priority 1 weight 100
Step 10
Returns the router to LISP configuration mode.exit
Example:
RP/0/RSP0/CPU0:router(config-lisp-afi)#exit
Step 11
Cisco ASR 9000 Series Aggregation Services Router Routing Configuration Guide, Release 5.3.x
665
Implementing Data Plane Security
Enable Source RLOC-based Decapsulation Filtering
