Cisco ASR 9000 Series Routing Configuration Guide

PurposeCommand or Action
Example:
On xTR:
RP/0/RSP1/CPU0:VKG-1#sh lisp vrf default session
Sessions for VRF default, total: 1, established: 1
Peer State Up/Down In/Out Users
204.1.0.1 Up 06:49:05 0/1 1
RP/0/RSP1/CPU0:VKG-1#
On MSMR:
sh lisp vrf default session
Sessions for VRF default, total: 2, established: 2
Peer State Up/Down In/Out Users
201.1.0.1 Up 06:48:49 1/0 0
202.1.0.1 Up 06:48:36 2/0 0
RP/0/RSP0/CPU0:VKG-4#
On a LISP device, to display decapsulation
filter-related data for the selected source
show lisp decapsulation filter
Example:
RP/0/RSP0/CPU0:lisp9-a9k-1#show lisp eid-table se2 decapsulation
filter
Step 4
RLOCs, use the show lisp decapsulation filter
command in the EXEC configuration mode.
In this example, decapsulation filter
LISP decapsulation filter for EID table vrf se2 (IID 16777212),
information is displayed on an (P)xTR for
5 entries
Instance-ID (IID 16777212). In this output,
Source RLOC Added by
22:22::10 MS 190::190
five source RLOC addresses are defined, and
33:33::20 MS 190::190
all members of this list were defined within the
88:88::30 MS 190::190
99:99::30 MS 190::190
list provided by the reliable transport session
with the Map-Server.
110:110::40 MS 190::190
RP/0/RSP0/CPU0:lisp9-a9k-1#
In this example, decapsulation filter summary
information is displayed on an (P)xTR.
show cef vrf [locator-vrf] address_family lisp decapsulation [ instance-id
EID-instance-ID ] detail location RLOC-facing LC
Example:
RP/0/RSP0/CPU0:lisp9-a9k-1#show cef ipv6 lisp decapsulation
instance-id 16777212 loc 0/0/cpu0
Step 5
Number of EID tables handling LISP payload received in this table:
3
Transport LISP ipv6 packets received in VRF: default, Instance
ID: 16777212
Payload IPv4 is : decapsulated
Payload IPv6 is : decapsulated
Payload switched in VRF : se2 (0xe000001d/0xe080001d)
H/W driver signalled : active
Binding in retry : no
Source RLOC Prefix Filter : enabled
Lookup statistics (s/w) :
Misses : 8
Matches (historic) : 0
H/W driver signalled : active
Binding in retry : no
Platform space : allocated
Len Prefix Action Matches Attributes
128 22:22::10 accept 0 h/w [active, plt space]
128 33:33::20 accept 0 h/w [active, plt space]
128 88:88::30 accept 0 h/w [active, plt space]
Cisco ASR 9000 Series Aggregation Services Router Routing Configuration Guide, Release 5.3.x
670
Implementing Data Plane Security
Verify Data Plane Security Configurations
