Chapter 10 Configuring IEEE 802.1x Port-Based Authentication
Configuring 802.1x Authentication
802.1x Authentication Configuration Guidelines
These section has configuration guidelines for these features:
• 802.1x Authentication, page 10-35
• VLAN Assignment, Guest VLAN, Restricted VLAN, and Inaccessible Authentication Bypass,
page 10-37
• MAC Authentication Bypass, page 10-37
• Maximum Number of Allowed Devices Per Port, page 10-38
802.1x Authentication
These are the 802.1x authentication configuration guidelines:
• When 802.1x authentication is enabled, ports are authenticated before any other Layer 2 or Layer 3
features are enabled.
• If you try to change the mode of an 802.1x-enabled port (for example, from access to trunk), an error
message appears, and the port mode is not changed.
Number of seconds between re-authentication
atte
mpts
3600 seconds.
Re-authentication number 2 times (number of times that the switch restarts the authentication process
be
fore the port changes to the unauthorized state).
Quiet period 60 seconds (number of seconds that the switch remains in the quiet state
f
ollowing a failed authentication exchange with the client).
Retransmission time 30 seconds (number of seconds that the switch should wait for a response to
a
n EAP request/identity frame from the client before resending the request).
Maximum retransmission number 2 times (number of times that the switch will send an EAP-request/identity
fr
ame before restarting the authentication process).
Client timeout period 30 seconds (when relaying a request from the authentication server to the
clie
nt, the amount of time the switch waits for a response before resending the
request to the client.)
Authentication server timeout period 30 seconds (when relaying a response from the client to the authentication
se
rver, the amount of time the switch waits for a reply before resending the
response to the server.)
You can change this timeout period by using the d
ot1x timeout
server-timeout interface configuration command.
Guest VLAN None specified.
Inaccessible authentication bypass Disabled.
Restricted VLAN None specified.
Authenticator (switch) mode None specified.
MAC authentication bypass Disabled.
Table 10-4 Default 802.1x Authentication Configuration (continued)
Feature Default Setting

Cisco Catalyst 3750-E Specifications

General

Series	Catalyst 3750-E
Switching Capacity	32 Gbps
Stacking Bandwidth	32 Gbps
StackWise Plus	Yes
Layer Support	Layer 3
MAC Address Table Size	12, 000 entries
RAM	256 MB
Flash Memory	64 MB
Memory	256 MB DRAM, 64 MB Flash
Operating Temperature	32 to 113°F (0 to 45°C)
Ports	48 10/100/1000 Ethernet ports
Form Factor	Rack-mountable
Jumbo Frame Support	Yes
Input Voltage	100 to 240 VAC
Storage Temperature	-25 to 70 °C
Relative Humidity	10 to 90% non-condensing
