10-62
Catalyst 3750-E and 3560-E Switch Software Configuration Guide
OL-9775-08
Chapter 10 Configuring IEEE 802.1x Port-Based Authentication
Configuring 802.1x Authentication
This example shows how to configure a switch as a supplicant:
Switch# configure terminal
Switch(config)# cisp enable
Switch(config)# dot1x credentials test
Switch(config)# username suppswitch
Switch(config)#
password myswitch
Switch(config)# dot1x supplicant force-multicast
Switch(config)# interface gigabitethernet1/0/1
Switch(config-if)# s
witchport trunk encapsulation dot1q
Switch(config-if)# switchport mode trunk
Switch(config-if)# d
ot1x pae supplicant
Switch(config-if)# d
ot1x credentials test
Switch(config-if)# end
Configuring NEAT with Auto Smartports Macros
You can also use an Auto Smartports user-defined macro instead of the switch VSA to configure the
authenticator switch. For Auto Smartports macros, see Auto Smartports Macros Configuration Guide
and Release Notes for Auto Smartports Macros.
Configuring 802.1x Authentication with Downloadable ACLs and Redirect URLs
In addition to configuring 802.1x authentication on the switch, you need to configure the ACS. For more
information, see the Cisco Secure ACS configuration guides.
Note You must configure a downloadable ACL on the ACS before downloading it to the switch.
After authentication on the port, you can use the sho
w ip access-list privileged EXEC command to
display the downloaded ACLs on the port.
Configuring Downloadable ACLs
The policies take effect after client authentication and the client IP address addition to the IP device
tracking table. The switch then applies the downloadable ACL to the port.
Beginning in privileged EXEC mode:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ip device tracking Sets the ip device tracking table.
Step 3
aaa new-model Enables AAA.
Step 4
aaa authorization network default local
group radius
Sets the authorization method to local. To remove the
authorization method, use the no aaa authorization network
default local group radius command.
Step 5
radius-server vsa send authentication Configure the radius vsa send authentication.
Step 6
interface interface-id Specify the port to be configured, and enter interface
configuration mode.
