Cisco Catalyst 3750-E User Manual

40-8
Catalyst 3750-E and 3560-E Switch Software Configuration Guide
OL-9775-08
Chapter 40 Configuring IP Unicast Routing
Configuring IP Addressing
Classless Routing
By default, classless routing behavior is enabled on the switch when it is configured to route. With
classless routing, if a router receives packets for a subnet of a network with no default route, the router
forwards the packet to the best supernet route. A supernet consists of contiguous blocks of Class C
address spaces used to simulate a single, larger address space and is designed to relieve the pressure on
the rapidly depleting Class B address space.
In Fi
gure 40-2, classless routing is enabled. When the host sends a packet to 120.20.4.1, instead of
discarding the packet, the router forwards it to the best supernet route. If you disable classless routing
an
d a router receives packets destined for a subnet of a network with no network default route, the router
discards the packet.
Figure 40-2 IP Classless Routing
In Figure 40-3, the router in network 128.20.0.0 is connected to subnets 128.20.1.0, 128.20.2.0, and
128.20.3.0. If the host sends a packet to 120.20.4.1, because there is no network default route, the router
di
scards the packet.
Host
128.20.1.0
128.20.2.0
128.20.3.0
128.20.4.1
128.0.0.0/8
128.20.4.1
IP classless
45749
128.20.0.0

Cisco Catalyst 3750-E Specifications

General

Series	Catalyst 3750-E
Switching Capacity	32 Gbps
Stacking Bandwidth	32 Gbps
StackWise Plus	Yes
Layer Support	Layer 3
MAC Address Table Size	12, 000 entries
RAM	256 MB
Flash Memory	64 MB
Memory	256 MB DRAM, 64 MB Flash
Operating Temperature	32 to 113°F (0 to 45°C)
Ports	48 10/100/1000 Ethernet ports
Form Factor	Rack-mountable
Jumbo Frame Support	Yes
Input Voltage	100 to 240 VAC
Storage Temperature	-25 to 70 °C
Relative Humidity	10 to 90% non-condensing
