Page #657 background imageLoading...
Page #657 background image
24-23
Catalyst 3750-E and 3560-E Switch Software Configuration Guide
OL-9775-08
Chapter 24 Configuring IGMP Snooping and MVR
Displaying MVR Information
To return the interface to its default settings, use the no mvr [type | immediate | vlan vlan-id | group]
interface configuration commands.
This example shows how to configure a port as a receiver port, statically configure the port to receive
m
ulticast traffic sent to the multicast group address, configure Immediate Leave on the port, and verify
the results.
Switch(config)# mvr
Switch(config)# interface gigabitethernet1/0/2
Switch(config-if)# mvr type receiver
Switch(config-if)# mvr vlan 22 group 228.1.23.4
Switch(config-if)# mvr immediate
Switch(config)# end
Switch# show mv
r interface
Port Type Status Immediate Leave
---- ---- ------- ---------------
Gi1/0/2 RECEIVER ACTIVE/DOWN ENABLED
Displaying MVR Information
You can display MVR information for the switch or for a specified interface.
Step 8
show mvr
show mvr interface
or
show mvr members
Verify the configuration.
Step 9
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Ta b l e 24-6 Commands for Displaying MVR Information
Command Purpose
show mvr Displays MVR status and values for the switch—whether MVR is enabled or disabled,
th
e multicast VLAN, the maximum (256) and current (0 through 256) number of
multicast groups, the query response time, and the MVR mode.
show mvr interface [in
terface-id]
[members [vlan vlan-id]]
Displays all MVR interfaces and their MVR configurations.
When a specific interface is entered, displays this information:
Type—Receiver or Source
Status—One of these:
Active means the port is part of a VLAN.
Up/Down means that the port is forwarding or nonforwarding.
Inactive means that the port is not part of any VLAN.
Immediate Leave—Enabled or Disabled
If the member
s keyword is entered, displays all multicast group members on this port or,
if a VLAN identification is entered, all multicast group members on the VLAN. The
VLAN ID range is 1 to 1001 and 1006 to 4094.
show mvr members [i
p-address] Displays all receiver and source ports that are members of any IP multicast group or the
specified IP multicast group IP address.
