Page #814 background imageLoading...
Page #814 background image
35-10
Catalyst 3750-E and 3560-E Switch Software Configuration Guide
OL-9775-08
Chapter 35 Configuring Network Security with ACLs
Configuring IPv4 ACLs
Creating a Numbered Standard ACL
Beginning in privileged EXEC mode, follow these steps to create a numbered standard ACL:
Use the no
access-list access-list-number global configuration command to delete the entire ACL. You
cannot delete individual ACEs from numbered access lists.
Note When creating an ACL, remember that, by default, the end of the ACL contains an implicit deny
statement for all packets that it did not find a match for before reaching the end. With standard access
lists, if you omit the mask from an associated IP host address ACL specification, 0.0.0.0 is assumed to
be the mask.
This example shows how to create a standard ACL to deny access to IP host 171.69.198.102, permit
access to any others, and display the results.
Switch (config)# access-list 2 deny host 171.69.198.102
Switch (config)# access-list 2 permit any
Switch(config)# end
Switch# show ac
cess-lists
Standard IP access list 2
10 deny 171.69.198.102
20 permit any
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
access-list access-list-number {deny | permit}
source [source-wildcard] [log]
Define a standard IPv4 access list by using a source address and
wildcard.
The ac
cess-list-number is a decimal number from 1 to 99 or 1300
to 1999.
Enter de
ny or permit to specify whether to deny or permit access
if conditions are matched.
The so
urce is the source address of the network or host from which
the packet is being sent specified as:
The 32-bit quantity in dotted-decimal format.
The keyword any as an abbreviation for source and
source-wildcard of 0.0.0.0 255.255.255.255. You do not need
to enter a source-wildcard.
The keyword host as an abbreviation for source and
source-wildcard of source 0.0.0.0.
(Optional) The s
ource-wildcard applies wildcard bits to the
source.
(Optional) Enter lo
g to cause an informational logging message
about the packet that matches the entry to be sent to the console.
Step 3
end Return to privileged EXEC mode.
Step 4
show access-lists [number | name] Show the access list configuration.
Step 5
copy running-config startup-config (Optional) Save your entries in the configuration file.
