Cisco Catalyst 3750-E User Manual

10-57
Catalyst 3750-E and 3560-E Switch Software Configuration Guide
OL-9775-08
Chapter 10 Configuring IEEE 802.1x Port-Based Authentication
Configuring 802.1x Authentication
Configuring 802.1x Authentication with WoL
Beginning in privileged EXEC mode, follow these steps to enable 802.1x authentication with WoL. This
procedure is optional.
To disable 802.1x authentication with WoL, use the no
dot1x control-direction interface configuration
command.
This example shows how to enable 802.1x authentication with WoL and set the port as bidirectional:
Switch(config-if)# dot1x control-direction both
Configuring MAC Authentication Bypass
Beginning in privileged EXEC mode, follow these steps to enable MAC authentication bypass. This
procedure is optional.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the port to be configured, and enter interface configuration mode.
For the supported port types, see the “802.1x Authentication
Configuration Guidelines” section on page 10-35.
Step 3
dot1x control-direction {both | in} Enable 802.1x authentication with WoL on the port, and use these
keywords to configure the port as bidirectional or unidirectional.
• both—Sets the port as bidirectional. The port cannot receive packets
from or send packets to the host. By default, the port is bidirectional.
• in—Sets the port as unidirectional. The port can send packets to the
host but cannot receive packets from the host.
Step 4
end Return to privileged EXEC mode.
Step 5
show authentication interface-id
or
show dot1x interface in
terface-id
Verify your entries.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the port to be configured, and enter interface configuration mode.
For the supported port types, see the “802.1x Authentication
Configuration Guidelines” section on page 10-35.
Step 3
authentication port-control auto
or
dot1x port-control auto
Enable 802.1x authentication on the port.

Cisco Catalyst 3750-E Specifications

General

Series	Catalyst 3750-E
Switching Capacity	32 Gbps
Stacking Bandwidth	32 Gbps
StackWise Plus	Yes
Layer Support	Layer 3
MAC Address Table Size	12, 000 entries
RAM	256 MB
Flash Memory	64 MB
Memory	256 MB DRAM, 64 MB Flash
Operating Temperature	32 to 113°F (0 to 45°C)
Ports	48 10/100/1000 Ethernet ports
Form Factor	Rack-mountable
Jumbo Frame Support	Yes
Input Voltage	100 to 240 VAC
Storage Temperature	-25 to 70 °C
Relative Humidity	10 to 90% non-condensing
