Upgrading The Computer
Upgrading the Hard Disk Drive(s) 6 - 7
6
Removing the Hard Disk(s) from the Primary HDD Bay
1. Turn the computer off, remove the AC/DC adapter, turn it over and remove the bat-
tery.
2. Locate the hard disk bay cover and remove screws & .
3. Remove the hard disk bay cover .
RAID Hard Disks
All hard disks in a RAID
should be identical (the
same size and brand) in
order to prevent unex-
pected system behavior.
Figure 6 - 3
Primary HDD Bay
Cover Screws &
Cover Removal
To Next Page
