Clevo P570WM

Upgrading The Computer
6 - 18 Upgrading the System Memory (RAM)
6
16. Replace the screws and shielding plate .
17. Replace the keyboard and make sure you reconnect the keyboard cable.
18. Reconnect the keyboard ribbon cable to the locking collar socket, and the
keyboard LED cable to its locking collar socket.
Figure 6 - 18
Keyboard Shielding
Plate Insertion
Figure 6 - 19
Reconnect the
Keyboard Cables
23
23
24
25
24
25
