Clevo P570WM

Upgrading The Computer
Upgrading the System Memory (RAM) 6 - 21
6
4. Carefully (they may be hot) pull the plastic tabs to lift up the heatsink off the
computer.
5. Remove screws - from the fan unit, disconnect the fan cable , and lift the
fan unit off the computer.
Figure 6 - 23
CPU Heatsink
Removal
Figure 6 - 24
Fan Removal
15
16
16
15
15
17
20
21
22
21
19
20
17
18
22
